Rotatable endcap 900mm led tube 15w

Rotatable endcap 900mm led tube 15w

Rotatable end cap led T8 tube lamp

Category: LED Tube Tags: 15w t8 led tube, 900mm led tube, T8 led tube light, T8 tube

Description
Inquiry

Description

900mm led tube is prefect for replacing the traditional 30W 900mm T8 fluroscent tube,need to remove/bypass the ballast before replacement

basis information

1. product used chip: Epistar from taiwan
2. Led source: SMD2835 led
3. Cover: Available milk white cover & clear cover & strip cover
4. Base type: G13/rotatable G13 base
5. Material: High grade 6063 Extruded Alu

900mm led tube detail information

Code	Watt [w]	Led qty (pcs)	Input Vol (V.AC)	CRI (Ra)	PFC (Typ)	LPW (lm/w)	SIZE (mm)	Material
YC-T809	9W	SMD2835 48pcs	AC85-265V	≧75	≧95	100lm/w	6002630	PC+AL
YC-T8015	15W	SMD2835 72pcs	AC85-265V	≧75	≧95	100lm/w	9002630	PC+AL
YC-T8018	18W	SMD2835 96pcs	AC85-265V	≧75	≧95	100lm/w	12002630	PC+AL
YC-T8024	24W	SMD2835 120pcs	AC85-265V	≧75	≧95	100lm/w	15002630	PC+AL

Advantage :
1. Excellent performance: 18W. High light efficiency. Energy saving up to 70%. More than 35000hours lifespan.
2. Good lighting effect: Special design makes balanced lighting effect. Non dark area, non light spot.
3. High quality: High thermal conductivity heat sink. International brand LED (Epistar).
4. Long warranty: 3years

5.using safe driver-isolate driver

Features :
1. Using high brightness SMD2835 LED.
2. Pure aluminum heat sink, good heat dissipation ability
3. CE driver insures tube working steadily.
4. Clear cover, milky cover are available.

Application and case:
Underground garage lighting engineering, underground parking lot lighting engineering, lighting engineering, hospital garage opping lighting engineering, Banks, home indoor lighting and so on.
