Description

led downlights singapore series

1.use high brightness,low light decline.long life performance cree cob

2.Die-cast aluminum hgousing.powder coating.

3.glareless reflector creates visual comfort.cut-off angle<42.

4.high grade glass,transparent rate>93%

5.1090 aluminum reflector,mirrow-finished anodized.reflective rate>90%

6.Non dim.Triac dim.0-10V dim.dali dim are available.meet different customer request

7.use high quality driver,brand lifud to produce

led downlights singapore

1. availabe wattage :5W 7w 10w 15w

2.Model No:YC-TDCOB

3.Led chip:CREE cob or Bridgelux cob

4.Size:Ф90*90mm cut hole Ф75mm

5.CRI:80 and 0.95 PF

6.Bean Angle: availabe 15° 24° 38° 60°

7.Color Temp:3000K & 4000k & 6000k

8.working voltage:AC200-240V/50-60hz

9.using Driver:lifud driver

10. warranty: offer 3 years

11.lumens: 100lm/W

12. NON-Dim or 0-10V or Triac dimmable are available

Test report

10w 3000k 60degree

led downlights singapore

Case

Packaging information

each downlight packaged with white box, the white box size is 120*120*110mm,

30 pcs led downlights in one carton. the carton size is 620*255*360mm,

the Net weight per carton is 11.5KG, Gross weight per carton box is 15KG

Produce & delivery info

1.NO MOQ Request

2. quickly produce time: 3-5 working days

3.delivery by DHL/air /sea

certification

certificate
